Control Command; Remote Jack (Ci-V) Information; Data Format - Icom IC-9100 Instruction Manual

18

CONTROL COMMAND

D
The transceiver can be connected through an optional
-
CT-17 CI V LEVEL CONVERTER
RS-232C port. The Icom Communications Interface-V
(CI-V) controls the transceiver.
Up to 4 Icom CI-V transceivers or receivers can be
connected to the PC. See page 167 for setting the
CI-V condition using the set mode.
D
The CI-V system can be operated using the following
data formats. Data formats differ depending on com-
mand numbers. A data area or sub command is added
to some commands.
Controller to IC-9100
FE FE
FE FE
IC-9100 to controller
183
to a PC equipped with an
q w e r t
7C E0 Cn Sc
E0 7C Cn Sc
q w e r t
IC-9100
When the transceiver is connected to a PC with the
USB cable (purchased separately), the optional
CT-17 is not required.
OK message to controller
y u
Data area FD
Data area FD
y u
NG message to controller
9−15V DC
RS-232C
cable
ct-17
mini-plug cable
FE FE E0 7C FB
FE FE E0 7C FA
PC
FD
FD
