20
CONTROL COMMAND
Remote jack (CI-V) information
D
Command table (Continued)
Cmd. Sub cmd. Data
1A 05 0211 see p. 20-14 Send/read the GPS-A comment
0212 00 to 08
0213 00/01
0214 00/01
0215 00 to 02
0216 00 to 02
0217 00/01
0218 00 to 02
0219 00/01
0220 00 to 02
06 see p. 20-14 Send/read the DATA mode setting
1B 00 see p. 20-14 Send/read the Repeater tone
01 see p. 20-14 Send/read the Tone squelch fre-
02 see p. 20-14 Send/read the DTCS code and
07 see p. 20-14 Send/read the CSQL code (DV
1C 00 00
01
01 00
01
02
02 00
01
Description
Send/read the GPS Auto TX inter-
val setting
(00=OFF, 01=5 sec., 02=10 sec.,
03=30 sec., 04=1 min., 05=3 min.,
06=5 min., 07=10 min.,
08=30 min.)
Send/read the QSO Log setting
(00=OFF, 01=ON)
Send/read the RX History Log func-
tion setting
(00=OFF, 01=ON)
Send/read the QSO/RX Log CSV
format setting (Separator/Decimal)
(00=Separator is "," and
Decimal is ".",
01=Separator is ";" and
Decimal is ".",
02=Separator is ";" and
Decimal is ",")
Send/read the QSO/RX Log CSV
format setting (Date)
(00="yyyy/mm/dd",
01="mm/dd/yyyy",
02="dd/mm/yyyy")
Send/read the Weather Alert setting
(USA only)
(00=OFF, 01=ON)
Send/read the Memory Name
Display setting
[System language: English]
(00=OFF, 01=ON)
[System language: Japanese]
(00=OFF, 01=Normal, 02=Large)
Send/read the Display Type setting
for the DR mode
(00=Normal, 01=Large)
Send/read the Compass Direction
setting
(00=Heading Up, 01=North Up,
02=South Up)
frequency
quency
polarity
mode)
Send/read the Transceiver's status
(RX)
Send/read the Transceiver's status
(TX)
Send/read Antenna tuner OFF
(through)
Send/read Antenna tuner ON
Send/read the Manual tuning selec-
tion
Send/read Transmit frequency
monitor check OFF
Send/read Transmit frequency
monitor check ON
Cmd. Sub cmd. Data
1E 00
01 see p. 20-12 Read the TX band edge frequen-
1E 02
03 see p. 20-12 Send/read the User-set TX band
1F 00 see p. 20-14 Send/read the DV MY call sign
01 see p. 20-14 Send/read the DV TX call signs
02 see p. 20-14 Send/read the DV TX message
20 00 00 00/01*
01 see p. 20-15 Output the DV RX Call signs
02 see p. 20-15 Read the DV RX Call signs
01 00 00/01*
01 see p. 20-15 Output the DV RX message
02 see p. 20-15 Read the DV RX message
02 00 00/01*
01 see p. 20-15 Output the DV RX status
02 see p. 20-15 Read the DV RX status
Output setting is automatically turned OFF after turning the
* 3
power OFF, then ON.
20-10
Description
Read number of available TX fre-
quency band
cies
Read number of User-set TX fre-
quency band
edge frequencies
3 Send/read the Auto DV RX Call
signs output setting
(00=OFF, 01=ON)
3 Send/read the Auto DV RX mes-
sage output setting
(00=OFF, 01=ON)
3 Send/read the Auto DV RX status
output setting
(00=OFF, 01=ON)
