17
SET MODE
Function Set mode (Continued)

Auto Repeater

Function > SPLIT/DUP > Auto Repeater (Auto Repeat-
er)
This item appears only in the Korean and U.S.A. ver-
sion transceivers.
The auto repeater function automatically turns the du-
plex operation and tone encoder* ON or OFF.
The offset and repeater tone* are not changed by the
auto repeater function. Reset these setting values, if
necessary.
For Korean versions
• OFF: Turns the function OFF.
• ON: Turns ON the duplex operation and tone encod-
er*. (Default)
For U.S.A. version
• OFF: Turns the function OFF.
• ON (DUP): Turns ON the duplex operation
only. (Default)
• ON (DUP, TONE): Turns ON the duplex operation and
tone encoder*.
* The tone encoder will not be turned ON in the DV mode.
Auto Start
Function > Tuner > Auto Start (Tuner (Auto Start))
Turn the Automatic Antenna Tuner function ON or OFF
for an external antenna tuner (like the optional AT-180).
This function is for only the HF bands.
• OFF: Tuning starts only when
• ON: The external antenna tuner automatically starts
tuning when the SWR is high, even if the tuner
is turned OFF.
PTT Start
Function > Tuner > PTT Start (Tuner (PTT Start))
When [PTT] is pushed after the operating frequency is
changed more than 1% from the last tuned frequency,
the external antenna tuner (optional AH-4 or AT-180)
automatically starts tuning.
• OFF: Tuning starts only when
• ON : (AH-4) Automatically starts tuning when [PTT] is
pushed on a new frequency, whether the
external antenna tuner is ON or OFF
(AT-180) Automatically starts tuning when [PTT]
is pushed on a new frequency, only if
the internal antenna tuner is ON
(Default: OFF)
is pushed.
TUNER/CALL
(Default: OFF)
is pushed.
TUNER/CALL
17-20
[TUNER] Switch
Function > Tuner > [TUNER] Switch ([TUNER] Switch)
Select whether or not to store the AT-180's status on
each band.
When you change the operating frequency, this func-
tion will automatically select the correct AT-180's status,
or you must do it manually.
• Manual: You must manually change the AT-180's sta-
tus by pushing [TUNER].
• Auto: The AT-180's status memorized by the band
memory is automatically selected. You can
also manually change it by pushing [TUN-
ER].
[SPEECH/LOCK] Switch
Function > [SPEECH/LOCK] Switch ([SPEECH/LOCK]
Switch)
Select the switch action.
SPEECH
• SPEECH/LOCK: Pushing
voice synthesizer function.
Holding down
dial lock function ON or OFF.
• LOCK/SPEECH: Pushing
function ON or OFF.
Holding down
the voice synthesizer function.
Lock Function
Function > Lock Function (Lock Function)
The dial lock function prevents frequency changes by
accidental movement of the tuning dial. The lock func-
tion electronically locks the dial.
• MAIN DIAL: When Lock Function is activated, the
Dial is disabled.
• PANEL: When Lock Function is activated, the
panel is disabled.
Functions except for [AF], [RF/SQL],
[PWR], [SPEECH/LOCK] are inhibited.
Memopad Numbers
Function > Memopad Numbers (Memopad Numbers)
Set the number of usable memopad channels to either
5 or 10.
See page 11-13 for details.
(Default: Auto)
(Default: SPEECH/LOCK)
turns ON the
SPEECH
turns the
SPEECH
turns the dial lock
SPEECH
turns ON
SPEECH
(Default: MAIN DIAL)
(Default: 5)
