Chapter 4. CONNECTOR PINOUTS

4.1

External Connections

External cables are attached to connectors on the rear panel. The connector configurations differ
between chassis type and revision (70/140 MHz vs. L-Band, and initially released chassis vs.
Rev. A and later), as shown in Figure 4-1.
The initially released chassis and the Rev. A chassis differ as follows:
Initially released chassis
Rev. A and later chassis
Refer to the applicable Data Interface chapter for pinouts.
Initially released chassis (70/140 MHz shown
Rev. A and later chassis (70/140 MHz shown

Figure 4-1. Rear Panel View

J4: RJ-45, Ethernet
J6: RJ-45, SerDes
J7: SMA-F, External Input
J4: RJ-45, Ethernet
J6: 9 Pin D-F, Async Channel
J7: BNC-F, External Input
Slot 1
4–1
Slot 2
)
)
