3.1
Connector Overview
The rear panel connectors, shown in Figure 3-1, provide all necessary external connections
between the modem and other equipment. Table 3-1 on the next page summarizes the connectors
provided on the rear panel interface, grouped according to service function.
Chapter 3. REAR PANEL
CONNECTOR PINOUTS
CDM-625 with AC Power Option
CDM-625 with DC Power Option
Figure 3-1. CDM-625 – Rear Panel View
3–1
