14 • Serial port configuration
Example: Displaying Frame Relay information
The following example displays the Frame Relay configuration settings for the serial interface.
SN(cfg)#port serial 0 0
SN(prt-ser)[0/0]# show framerelay
Framerelay Configuration:
Port LMI-Type
----------------------------------------------------------
serial 0 0 0 ansi
PVC Configuration:
Port DLCI
----------------------------------------------------
serial 0 0 0 1

Examples

Displaying serial port information

The following example shows the commands used to display serial port configuration settings for a SmartNode
2300 series device. Moreover a typical command output is listed below.
SN>enable
SN#configure
SN(cfg)#show port serial
Serial Interface Configuration
-------------------------------------
Port
State
Hardware Port
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation
172
Keepalive
10
State
open
: serial 0 0 0
: OPENED
: X.21
: DTE
: CRC-16
: 1
: framerelay
SmartWare Software Configuration Guide
Fragmentation
enabled
Encaps Binding
rfc1490 wan@router
