SmartWare Software Configuration Guide

Telnet Procedure

Before you begin to use the CLI to input configuration commands, do the following:
1. Set up the SmartNode as described in the getting started guide included with your SmartNode device.
2. Connect the host (PC) or hub to the ETH 1 (LAN) port of your SmartNode with crossover or straight-
thru cables, according to Appendix A of the getting started guide included with your SmartNode device.
3. Power on your SmartNode and wait until the "Run" LED lights.
4. Be sure that the IP address and subnet mask of your host are in the same address range as the ETH 1
(LAN) port of your SmartNode.
5. Open a Telnet session to the ETH 1 (LAN) port with the IP address 10.1.0.10 of your SmartNode.
6. Proceed with logging in.

Log onto SmartWare

Accessing your SmartNode via the local console port or via a Telnet session will open a login screen. The fol-
lowing description of the login process is based on a Telnet session scenario but is identical to that used when
accessing via the local console port.
The opening Telnet screen you see will resemble that shown in
address of the target SmartNode.
A factory preset administrator account with name administrator and an empty password is programmed into
the SmartWare at the factory. For that reason use the name administrator after the login prompt and simply
press the "Enter" key after the password prompt.
Upon logging in you are in operator execution mode, indicated by the ">" as command line prompt. Now you
can enter system commands.
Note Details on screen in
and window header bar, may be different on your SmartNode device.
Accessing the SmartWare CLI task list
Figure 11. Login display
figure 11, such as the IP address in the system prompt
figure 11. The window header bar shows the IP
