Copying Driver Software From A Network Server To Flash Memory - Patton electronics SmartNode Series Software Configuration Manual

SmartWare Software Configuration Guide
Mode: Administrator execution
Step
1 node (cfg)# copy tftp:// node-ip-address / b flash:
Example: Copy system images from a network server to Flash memory
The following example shows how to download the system image file and command line syntax definition file
from the TFTP server at IP address 172.16.36.80. The download is defined by a script file, which has to be
downloaded first. After downloading the script file the system image file and command line syntax definition
file are downloaded automatically.
SN>enable
SN#configure
SN(cfg)#copy tftp://172.16.36.80/sn2300/build22032/b flash:
Completed image download
Completed file download /flash/cli/spec.xml
SN(cfg)#
Note
When encountering problems due to memory exhaustion (message Parsing
batch file...% APP - OUT OF MEMORY.) shutdown the H.323 gateway
prior to initiating the download command as follows (which will tempo-
rarily free the required memory):
After the successful download either issue the 'reload' command (in order to start the IPNode with the new
software) or restart the H.323 gateway thus enabling calls again (with the current software):
node(gw-h323)[h323]#no shutdown

Copying driver software from a network server to Flash memory

Driver software images contain driver software that is to be downloaded to hardware devices such as optional
interface cards.
Downloading a driver software image file means storing it permanently at a defined location within the flash
memory on the motherboard or in the non-volatile memory of an optional interface card. To download driver
software image file a special download script file must be used.
System image handling task list
Command
node(gw-h323)[h323]#shutdown
6 • System image handling
Purpose
Downloads the script file b from the TFTP
server at address node-ip-address and starts
the system image download process. This
progress is visualized with a counter, count-
ing up from 0 to 100% according to the
downloaded amount of the file size for each
file that needs to be downloaded.
75
