SmartWare Software Configuration Guide
The cos rx-map and cos tx-map commands above need service class mapping table entries, which has to be
entered as additional command argument. The command syntax is:
cos rx-map—layer 2 class of service value as service class value
cos tx-map—service class value as layer 2 class of service value
Do the following to configure the class of service map:
1. Configure the class of service map table for the outgoing data traffic. Every provided service can be
mapped to a Class of Service.
2. Configure the class of service map table for the incoming data traffic. Every received Class of Service can be
assigned to a service type

Adding a receive mapping table entry

The receive mapping table defines the conversion of receiving Layer 2 CoS to service class value into a Smart-
Ware-specific service class value. Each conversion is stored as a mapping table entry. Therefore the receive map-
ping table consists of several mapping table entries.
This procedure describes how to add a receive mapping table entry
Mode: Configure
Step
1
node (cfg)#port ethernet slot port
2
node (prt-eth)[ slot/port ]#cos rx-map layer
2 class of service value as service class value
Example: Adding a receive mapping table entry
The following example shows how to add a receive mapping table entry, which converts a layer 2 class of ser-
vice value of 2 into a service class value of 4 for the Ethernet port on slot 0 and port 0 of a SmartNode 1000,
2000, or 4000 series device.
SN(cfg)#port ethernet 0 0
SN(prt-eth)[0/0]#cos rx-map 2 as 4

Adding a transmit mapping table entry

The transmit mapping table defines the conversion of transmitting SmartWare-specific service class value into
a Layer 2 CoS to service class value. Each conversion is stored as a mapping table entry. Therefore the transmit-
ting mapping table consists of several mapping table entries.
This procedure describes how to add a transmit mapping table entry
Ethernet port configuration task list
Command
12 • Ethernet port configuration
Purpose
Enters Ethernet port configuration mode for the
interface on slot and port
Adds a receive mapping table entry, which con-
verts a layer 2 class of service into a service class
value
133
