14 • Serial port configuration

Introduction

This chapter provides an overview of the serial port and describes the tasks involved in configuring the serial
port through the Patton SmartWare, it includes the following sections:
• Serial port configuration task List
• Configuration tasks
• Examples
The SmartNode 2000 series device supports both the V.35 and X.21 standard for synchronous serial interfaces
with speeds up to 2 Mbps. The V.35 standard is recommended for speeds up to 48 kbps, although in practice
it is used successfully at 4 Mbps. The X.21 standard is recommended for data interfaces transmitting at rates
up to 2 Mbps and is used primarily in Europe and Japan.
The synchronous serial interface supports full-duplex operation and allows interconnection to various serial network
interface cards or equipment. Refer to the getting started guide included with your SmartNode device for specific
information regarding the connector pinout and the selection of cables to connect with 3rd party equipment.
The SmartNode 2000 series device supports the Frame Relay protocol on the synchronous serial interface.
Frame Relay is an example of a packet-switched technology. Packet-switched networks enable end stations to
dynamically share the network medium and the available bandwidth. Variable-length packets are used for more
efficient and flexible transfers. These packets then are switched between the various network segments until the
destination is reached. Statistical multiplexing techniques control network access in a packet-switched net-
work. The advantage of this technique is that it provides more flexibility and more efficient use of bandwidth.
Serial port configuration task list
Perform the tasks in the following sections to configure a synchronous serial interface:
• Disabling an interface (see
• Enabling an interface (see
• Configuring the serial encapsulation type (see
• Configuring the hardware port protocol (see
• Configuration of the active clock edge (see
• Entering Frame Relay mode (see
• Configuring the LMI type (see
• Configuring the keep-alive interval (see
• Enabling fragmentation (see
• Entering Frame Relay PVC configuration mode (see
• Configuring the PVC encapsulation type (see
• Binding the Frame Relay PVC to IP interface (see
• Disabling a Frame Relay PVC (see
• Displaying Frame Relay information (see
160
page 161)
page 161)
page
page
page 164)
page 165)
page 165)
page 166)
page 167)
page
page 170)
page 171)
SmartWare Software Configuration Guide
162)
163)
page 168)
169)
page 169)
