SmartWare Software Configuration Guide 6 • System image handling
Type 'help' to display a list of the available commands in the Diagnostic domain (see figure 19).
Figure 19. Diagnostic Display
The command 'ping' allows you to verify the IP connectivity within a network.
The various sectors of the SmartNode flash memory can be tested with the command 'flashtest'.
To delete the contents of the EFS the command 'eraseefs' is used.

Bootloader (for SmartNode 4110/4520 Series)

The SmartNode 4110/4520 Series comes with a new Bootloader, the 'RedBoot Bootloader'. It offers new fea-
tures such as console access to the Bootloader and downloading application images (e.g. SmartWare) via the
serial link of the console.

Start Bootloader

To start the Bootloader, reload the system and press Ctrl-C (when the message Press ^C to abort boot script, ...
appears on the console screen). The follow prompt will be displayed:
RedBoot>
Enter 'help' to get an overview of the available commands. The cursor keys (up, down, left, right) are not work-
ing, use CTRL-N (for up) and CTRL-P (for down) instead. Overwriting and inserting does not work either.
Commands can be abbreviated as long as they do not become ambiguous.
