SmartWare Software Configuration Guide
Step
5 node (if-ip)[name]#use profile napt name Assigns the NAPT profile name to applied to
(optional)
Example: Create an IP interface for PPP
The procedure below creates an IP interface which can be used for all three types of link layers. The command
lines 'tcp adjust-mss' only apply to Ethernet link layers.
SN(cfg)#context ip router
SN(ctx-ip)[router]#interface ppp_interface
SN(if-ip)[ppp_int~]#point-to-point
SN(if-ip)[ppp_int~]#ipaddress unnumbered
SN(if-ip)[ppp_int~]#tcp adjust-mss rx mtu
SN(if-ip)[ppp_int~]#tcp adjust-mss tx mtu

Creating a PPP subscriber

One or more PPP subscriber shall be configured if either PPP peer requires authentication. This procedure
describes how to create a PPP subscriber
Mode: Configure
Step Command
1 node (cfg) # subscriber ppp name
node (subscr)[name]# dial {in|out}
2
3 node (subscr)[name]# [no] authentication {
(chap pap) | {chap|pap} }
PPP configuration task list
Command
21 • PPP configuration
Purpose
this IP interface. See 11,
ration" on page 119 on
to create a NAPT profile.
Purpose
Creates the new subscriber name , which con-
tains the authentication settings.
Defines the direction of the connection establish-
ment with PPP over ISDN. This information allows
to use different subscribers for incoming and out-
going calls.
With the other two link layers, set the direction as
follows:
PPP over Ethernet: 'dial out'
•
• PPP over Serial: 'dial in'
Defines the authentication protocol to be used,
PAP and/or CHAP
"NAT/NAPT configu-
page 119 to learn how
249
