SmartWare Software Configuration Guide
[08004D]
RELEASE (Generic Q.931)
[0803038090]
Cause : normal call clearing
transit network - CCITT - Q.931
14:14:50 CALL
SN2#

Debug ISDN data

To obtain actual information about the ISDN layers you can use the ISDN debug commands. The show com-
mand displays information about the actual ISDN status and about actual ISDN sessions. The debug com-
mand enables the ISDN debug monitor to show layer 1 to layer 3 information. This information is mainly
useful for experienced users.
This procedure describes how to get information about ISDN data
Mode: Administrator execution
Step
1 node #show isdn bearer-channels [ detail-
level ]
2 node #show isdn sessions [ detail-level ]
3 node #debug isdn [ slot ] [ port ] [ layer ]

Debug H.323 data

You can use the H.323 debug commands if there are problems with setting up and establishing calls over
H.323. The show command displays the actual H.323 configuration or the actual status of the H.323 stack,
e.g. ongoing calls or registration state. The debug command enables the H.323 debug monitor to show specific
information for a call, such as status, used codecs or transposed messages. There are more than forty different
debug monitors such as 'q931', 'ras' or 'signaling'. For a list of all available debug monitors refer to the CLI
online help.
This procedure describes how to get information about H.323 data
Mode: Administrator execution
Step
1 node #show gateway h323 config
2 node #show gateway h323 status
3 node #debug gateway h323 signaling
[ detail-level ]

Debug session control data

Voice application data contains voice data that is transposed between ISDN and VoIP protocols. The show
command displays registered subsystems (e.g. ISoIP and Datapath) or open VoIP data sessions. The debug
Debugging task list
> [8000] DROPPED
Command
Command
Purpose
Show the actual ISDN status
Show the actual status of ISDN sessions
Enable the ISDN debug monitor to get layer 1 to
layer 3 information.
Purpose
Show the actual H.323 configuration
Show the actual status of the H.323 stack.
Enable the H.323 debug monitor to get informa-
tion about the transposed H.323 data. Debug
monitor 'signaling' is mostly used.
31 • VoIP debugging
