29 • Gateway configuration
Step 3 node (gw-h323)[h323]#h235security
encrypted-password h235-password
or
node (gw-h323)[h323]#h235security clear-
password h235-password
Step 4 node (gw-h323)[h323]#h235security time-
window time-window
node (gw-h323)[h323]#h235security version
Step 5
{v1 | v2}
Step 6 node (gw-h323)[h323]#h235security sender-
id sender-id
Step 7 node (gw-h323)[h323]#h235security gen-
eral-id general-id
Step 8 node (gw-h323)[h323]#h235security
Step 9 node (gw-h323)[h323]#show h235security
node (gw-h323)[h323]#debug h235security
Step 10
[ debug-level ]
Example: Switch on H.235 security
The following example shows how to use the password encryption tool and how to enable H.235 security.
Additionally the H.235 security debug monitor is enabled.
Generate the encrypted H.235 password from 'myh235pwd':
C:\>getcryptopassword myh235pwd 12d3f4e76a83c6dd1067a6d34fe5cb21
H.235 Password
Encrypted H.235 Password: 21dafa5dfc7399e5cef9cc138dabd22f
Master Password
Hash of Master Password : bc210d2244a1afd2e7da7a54a1a8c179403220c4
370
Command
: myh235pwd
: 12d3f4e76a83c6dd1067a6d34fe5cb21
SmartWare Software Configuration Guide
Purpose
Sets the password used for crypto token cal-
culation. The password is entered encrypted.
The password to be entered is the output of
the tool 'getcryptopassword.exe'.
Configures the password used for crypto
hashed token calculation. The password is
entered in clear text (min. 1, max. 12 alpha-
numeric characters).
N.B.: Do not use this command over insecure
links (subject to wiretapping). If you enter the
password as clear text, you don't need to
configure a master-password.
Sets the time window used for timestamp
comparison by H.235. If a received H.323
message with H.235 crypto token has a
timestamp outside the time window (relative
to the local time) the message is refused.
General there exist two H.235 versions. Use
'v1' if 'v2' does not work. In 'v1' "sender-id"
and "general-id" must not be specified.
Sets the ID of the Node. Must be a string con-
taining 2, 4, 6, ... characters.
Sets the ID of the entity to which the message
is sent, e.g. a gatekeeper. Must be a string
containing 2, 4, 6, ... characters.
If all parameters are set, enables H.235
security. Otherwise returns an error mes-
sage.
Shows status of H.235 security module.
Enables the H.235 debug monitor to display
information for every received and sent
H.323 signaling message.
Gateway configuration task list
