SmartWare Software Configuration Guide
Example: Configuring the active clock edge
The following example enables sending of the data on the negative edge on slot 0 and port 0 of a SmartNode
2300 series device. Check that in the command output of show port serial Transmit Clock is set to inverted.
SN(cfg)#port serial 0 0
SN(prt-ser)[0/0]#transmit-data-on-edge negative
SN(prt-ser)[0/0]#show port serial
Serial Interface Configuration
------------------------------
Port
State
Hardware Port
Transmit Edge
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation

Enter Frame Relay mode

This section describes the tasks for configuring Frame Relay for the serial interface on a SmartNode series 2000
device, after setting the basic serial interface parameters according to the previous sections.
This procedure desribes how to enter the Frame Relay configuration mode
Mode: Administrator execution
Step Command
1 node (cfg)#port serial slot port
2 node (prt-ser)[ slot/port ]#framerelay Enters the Frame Relay configuration mode
3 node (frm-rel)[ slot/port ]#
Example: Enter Frame Relay mode
The following example shows how to enter into the Frame Relay configuration mode for the serial interface on
slot 0 and port 0 of a SmartNode 2300 series device.
SN(cfg)#port serial 0 0
SN(prt-ser)[0/0]#framerelay
SN(frm-rel)[0/0]#
Configuring the LMI type
For a frame relay network, the line protocol is the periodic exchange of local management interface (LMI)
packets between the SmartNode series 2000 device and the frame relay provider equipment. If the SmartNode
series 2000 device is attached to a public data network (PDN), the LMI type must match the type used on the
public network.
Serial port configuration task list
: serial 0 0 0
: CLOSED
: X.21
: inverted
: DTE
: CRC-16
: 1
: framerelay
Selects the serial interface on slot and port
Frame Relay configuration mode prompt is displayed
14 • Serial port configuration
Purpose
165
