SmartWare Software Configuration Guide
Table 14. SmartNode Models and their Unique sysObjectID (Continued)
SmartNode Model
SmartNode 4114
SmartNode 4116
SmartNode 4118
SmartNode 4522
SmartNode 4524
SmartNode 4526
SmartNode 4528
According to table 14, an SNMP get request to .iso.org.dod.internet.mgmt.mib-2.system.sysObjectID of a Smart-
Node 1200 device reads out a numeric OID of 1.3.6.1.4.1. 5349.2.2.1, which represents a SmartNode 1200
device. The mapping of the sysObjectID to each of the SmartNode model is realized with the SmartNode
product identification MIB.
SNMP tools
Patton recommends the AdventNet MibBrowser, TrapViewer and other SNMP tools. Check the AdventNet
Web server at http://www.adventnet.com for latest releases.
Refer to the section "Using the AdventNet SNMP Utilities" for more detailed information on how to use these
tools together with SmartNode 1000, 2000 or 4000 series devices.
SNMP configuration task list
To configure SNMP, perform the tasks described in the following sections. The tasks in the first three sections
are required; the tasks in the remaining sections are optional, but might be required for your application.
•
Setting basic system information (required) (see
•
Setting access community information (required) (see
•
Setting allowed host information (required) (see
•
Specifying the default SNMP trap target (optional) (see
SNMP tools
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4114
1.3.6.1.4.1. 5349.2.4.5.6
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4116
1.3.6.1.4.1. 5349.2.4.5.7
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4118
1.3.6.1.4.1. 5349.2.4.5.8
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4522
1.3.6.1.4.1. 5349.2.4.5.2
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4524
1.3.6.1.4.1. 5349.2.4.5.1
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4526
1.3.6.1.4.1. 5349.2.4.5.3
.iso.org.dod.internet.private.enterprises.inalp.products.sn4000.sn4528
1.3.6.1.4.1. 5349.2.4.5.4
The SNMP agent running in the SmartWare is SNMP version 1
(SNMPv1) compliant. Therefore both SNMP version 2 (SNMPv2)
and SNMP version 3 (SNMPv3) are not supported.
SysObjectID
page
212)
page
214)
page
215)
page
215)
18 • SNMP Configuration
211
