SmartWare Software Configuration Guide
The session control data task describes debugging of the data between the ISDN and VoIP protocols, and in
the voice over IP data task it is explained how to debug tones and codecs. Finally check event logs, which could
help you to find out the cause of a problem.
•

Verify IP connectivity

• Verify circuit switch connectivity (see
• Debug ISDN data (advanced) (see
• Debug H.323 data (advanced) (see
• Debug ISoIP data (advanced) (see
• Debug session control data (advanced) (see
• Debug Voice over IP data (advanced) (see
• Check event logs (see

Verify IP connectivity

With the following command you can verify that an IP packet can be sent to and received from the destination
host.
This procedure describes how to test connectivity by verifying IP accessibility of hosts
Mode: Administrator execution
Step
1 node #ping ipaddress [ number-of-packets ]
[timeout seconds ]
Example: Verify IP connectivity
The following example shows how to test the connectivity to a remote host by verifying the accessibility by the ping
command. Furthermore it shows the output if host 192.195.23.1 is not, and host 172.16.40.122 is reachable.
SN#ping 192.195.23.1 10 timeout 5
Sending 10 ICMP echo requests to 192.195.23.1, timeout is 5 seconds:
% No route to host
SN#
SN#ping 172.16.40.122
Sending 5 ICMP echo requests to 172.16.40.122, timeout is 1 seconds:
Reply from 172.16.40.122: Time <10ms
Reply from 172.16.40.122: Time <10ms
Reply from 172.16.40.122: Time <10ms
Reply from 172.16.40.122: Time <10ms
Reply from 172.16.40.122: Time <10ms
Ping statistics for 172.16.40.122:
Packets: Sent 5, Received 5, Lost 0 (0% loss),
RTT: Minimum <10ms, Maximum <10ms, Average <10ms
Debugging task list
page 398)
page 401)
page 401)
page 401)
page
page
page 405)
Command
401)
402)
Verify whether an IP host is reachable or not
31 • VoIP debugging
Purpose
397
