SmartWare Software Configuration Guide
Mode: Interface
Step
1 node (cfg)#context ip router
2 node (ctx-ip)[router]#interface if-name
node (if-ip)[ if-name ]#debug acl {in | out} [level]
3
Where the syntax is:
Keyword
if-name The name of the IP interface to which an access control list profile gets bound
level The detail level. Level 0 disables all debug output, level 7 shows all debug output.
in Specifies that the settings for incoming packets are to be changed.
out Specifies that the settings for outgoing packets are to be changed.
Example: Debugging access control list profiles
The following example shows how to enable debugging for incoming traffic of access control lists on interface
wan. On level 7 all debug output is shown.
SN(cfg)#context ip router
SN(cfg-ip)[router]#interface wan
SN(cfg-if)[wan]#debug acl in 7
The following example enables the debug monitor for access control lists globally.
SN#debug acl
The following example disables the debug monitor for access control lists globally.
SN#no debug acl
Access Control List configuration task list
Command
17 • Access control list configuration
Selects the IP router context
Selects IP interface if-name for which access
control list profile shall be debugged
Enables access control list debug monitor
with a certain debug level for the selected
interface if-name
Meaning
Purpose
