SmartWare Software Configuration Guide
Table 20 shows which clock-mode configurations are allowed for the SmartNode 1000 Series and which port is
used as the clock source.
Table 20. Clock-Modes and clock-sources for the SmartNode 1000 Series
Port 0 Port 1
clock-mode clock-mode
slave slave
master master
slave master
master slave
With the Interface Card IC-4BRV, Ports 0 and 1 can only be 'master'.
Note
The SmartNode 1400 needs to be rebooted twice after changing the clock-
source.
Example: Configuring Port as Euro-ISDN Interface
The following example shows how to configure port 0/0 as a Euro ISDN interface with user side signaling.
172.16.40.71(cfg)#port pstn 0 0
172.16.40.71(prt-pstn)[0/0]#l3proto dss1
172.16.40.71(prt-pstn)[0/0]#uni-side usr
172.16.40.71(prt-pstn)[0/0]#max-channels 2
The following example shows how to configure both ports of a SmartNode 1400 with network signaling but
receive the clock (via port 0) from the peer. The peer must be configured accordingly, i.e. port 0 as USR/clock
master and port 1 NET/clock slave.
172.16.40.71(cfg)#port pstn 0 0
172.16.40.71(prt-pstn)[0/0]#uni-side net
172.16.40.71(prt-pstn)[0/0]#clock-mode slave
172.16.40.71(prt-pstn)[0/0]#port pstn 0 1
172.16.40.71(prt-pstn)[0/1]#uni-side net
Configure BRI port parameters
The ISDN layer 2 of BRI ports can operate in point-to-point (pp) or point-to-multipoint (pmp) mode. Point-
to-multipoint is used to connect multiple terminals to an ISDN S-Bus. In some cases small PBXs are also con-
nected to the public ISDN in point-to-multipoint mode. Point-to-point is typically used to connect PBXs to a
public or private ISDN.
This procedure describes how to configure BRI port parameters
ISDN port configuration task list
Port 1 used as reference
Internal clock generation
Port 0 used as reference (The only configuration that SmartNode 1200
supports)
Not supported
27 • ISDN port configuration
Clock Source
