10 • IP interface configuration
Mode: Either operator or administrator execution
Step Command
1 node >ping ip-address
When using ping for fault isolation, it should first be run on the respective SmartNode interface, to verify that
the local LAN or WAN interface is up and running. Then hosts and gateways further and further away should
be "pinged". Round-trip times and packet loss statistics are computed. If duplicate packets are received, they
are not included in the packet loss calculation, although the round trip time of these packets is used in calculat-
ing the minimum/average/maximum round-trip time numbers. When five ICMP echo requests packets have
been sent and received a brief summary is displayed.
Example: Testing connections with the ping command
The following example shows how to invoke the echo protocol to the destination host at IP address
172.16.1.10 using the ping command from operator execution mode.
SN>ping 172.16.1.10
Sending 5 ICMP echo requests to 172.16.1.10, timeout is 1 seconds:
Reply from 172.16.1.10: Time <10ms
Reply from 172.16.1.10: Time <10ms
Reply from 172.16.1.10: Time <10ms
Reply from 172.16.1.10: Time <10ms
Reply from 172.16.1.10: Time <10ms
Ping statistics for 172.16.1.10:
Packets: Sent 5, Received 5, Lost 0 (0% loss),
RTT: Minimum <10ms, Maximum <10ms, Average <10ms

Traceroute

This procedure describes how to print the route (list of hops) packets take to network host.
Mode: Either operator or administrator execution
Step Command
node >traceroute ip-address
1

Examples

Deleting an IP interface

The following example shows how to delete an IP interface named wan, use the no command as following
demonstrated in IP context configuration mode.
List the existing interfaces in the IP context:
SN(ctx-ip)[router]#interface <?>
<interface>
lan
wan
116
Sends ICMP ECHO_REQUEST packets to network hosts at IP address ip-
address
prints the route (list of hops) packets take to network host.
New interface
Existing interface
Existing interface
