SmartWare Software Configuration Guide
Introduction
figure 82
on page 418 illustrates the configuration modes hierarchy. Each box contains the mode name, the
enter command and the prompt in a telnet console. Additionally all relationships between the instances of the
components through bind and link commands are illustrated. For example an instance of 'port ethernet' must
be bound to an 'IP interface' through the command '[no] bind interface <name> [<ip_context>]'.
SmartWare 2.20 command summary
The SmartWare 2.20 commands are collected in configuration modes as illustrated
commands in the configuration modes are listed. The configuration modes are listed in order as shown in
figure
82. The command summary is organized as follows:
Mode Name
Enter Command
Command 1
Exit
Mode Name
Several commands contain a lot of parameters and arguments. The command syntax is described as follows:
•
Arguments where you must supply the value are surrounded by <angle brackets>.
•
Optional arguments within commands are shown in square brackets ([ ])
•
Alternative parameters within commands are separated by vertical bars ( | ).
•
Alternative but required parameters are shown within grouped braces ({}) and are separated by vertical bars
( | ).
Introduction
B • Configuration mode overview
figure
82. Following all
417
