30 • VoIP profile configuration
Example: Enable Fax relay
The following example shows how to configure fax relay. The max bit rate is increased to 14400 kbps.
SN>enable
SN#configure
SN(cfg)#profile voip ISoIPProfile
SN(pf-voip)[ISoIPPr~]#fax transmission relay t38-udp
SN(pf-voip)[ISoIPPr~]#fax redundancy ls 1 hs 2
SN(pf-voip)[ISoIPPr~]#fax dejitter-max-delay 300
SN(pf-voip)[ISoIPPr~]#fax max-bit-rate 9600
SN(pf-voip)[ISoIPPr~]#fax detection fax-frames
Show VoIP profile configuration and assign it to a VoIP gateway
To activate a created VoIP profile it must be used by an H.323 or ISoIP gateway. Prior to using the profile by a
gateway it is possible to display the VoIP profiles.
Note
The default VoIP profile always exists. Settings such as fax/data can be
ignored at this time.
This procedure describes how to show the actual VoIP profiles and use it by a VoIP gateway.
Mode: Profile VoIP
Step
1 node (pf-voip)[ name ]#show profile voip
[name]
2 node (pf-voip)[ name ]#exit
3 node (cfg)#gateway gw-type gw-name
4 node ( gw-type )[ gw-name ]#use voip-profile
name
Example: Show VoIP profile configuration and assign it to a VoIP gateway
This example shows how to show all defined VoIP profiles and how to use the VoIP profile ISoIP profile by the
ISoIP gateway.
SN(pf-voip)[ISoIPPr~]#show profile voip
Profile default
------------------------------------------------------------------
dejitter settings: mode:
voice settings:
390
Command
max delay:
max packet loss:
shrink speed:
grow step:
grow attenuation:
hybrid loss:
non linear processor mode: adaptive
echo canceller:
silence compression:
SmartWare Software Configuration Guide
Purpose
Show all defined VoIP profiles or the VoIP profile
with name name
Change to gateway configuration mode.
The VoIP profile with name name is used by the
VoIP gateway.
adaptive
60 ms
4
1
1
1
6
enabled
disabled
VoIP profile configuration task list
