Patton electronics SmartNode Series Software Configuration Manual page 295

SmartWare Software Configuration Guide
bind port 2 1
interface pstn PublicPSTN
routing dest-table CalledNumberRouting
bind port 0 1
interface h323 CompanyOfficeA
routing dest-table CalledNumberRouting
remoteip 146.86.130.11
codec g711alaw64k
interface h323 CompanyOfficeB
routing dest-table CalledNumberRouting
remoteip 146.86.130.24
codec g711alaw64k
context cs switch
no shutdown
profile voip H323VoIPProfile
dtmf-relay
gateway isoip
shutdown
gateway h323
codec g711alaw64k 10 10
codec g723_6k3 10 10
codec g729 10 10
faststart
no ras
bind interface eth00 router
use voip-profile H323VoIPProfile
no shutdown
port ethernet 0 0
medium 10 half
encapsulation ip
bind interface eth00 router
no shutdown
port ethernet 0 1
medium 10 half
encapsulation ip
bind interface eth01 router
no shutdown
port isdn 2 0
down
channel-range 0 1
l2proto pp
l3proto pss1
max-channels 2
uni-side net
up
CS context configuration task list
23 • CS context overview
