14 • Serial port configuration
Mode: Administrator execution
Step
1 node (cfg)#port serial slot port
2 node (prt-ser)[ slot/port ]#no shutdown
3 node (prt-ser)[ slot/port ]#show port serial Displays the serial interface configuration.
Example: Enabling an interface
The example shows how to enable the built-in serial interface on slot 0 and port 0 of a SmartNode 2300 series
device. Check that in the command output of show port serial State is set to OPENED.
SN(cfg)#port serial 0 0
SN(prt-ser)[0/0]#no shutdown
SN(prt-ser)[0/0]#show port serial
Serial Interface Configuration
------------------------------
Port
State
Hardware Port
Transmit Edge
Port Type
CRC Type
Max Frame Length: 2048
Recv Threshold
Encapsulation
Configuring the serial encapsulation type
The synchronous serial interface supports the Frame Relay serial encapsulation method.
To set the encapsulation method used by a serial interface, use the encapsulation interface configuration
command.
This procedure desribes how to set the encapsulation type of the serial interface for frame relay
Mode: Administrator execution
Step
1 node (cfg)#port serial slot port
2 node (prt-ser)[ slot/port ]#encapsulation framerelay Sets the encapsulation for selected inter-
3 node (prt-ser)[ slot/port ]#show port serial
162
Command
: serial 0 0 0
: OPENED
: V.35
: normal
: DTE
: CRC-16
: 1
:
Command
SmartWare Software Configuration Guide
Purpose
Selects the serial interface on slot and port
Enable the interface
Selects the serial interface on slot and port
face to frame relay
Displays the serial interface configuration.
Purpose
Serial port configuration task list
