SmartWare Software Configuration Guide
H.323 and ISoIP interfaces are CS interface types that provides voice over IP settings in addition to the general
CS interface parameters. All H.323 and ISoIP interface on the CS context are implicitly bound to the H.323
or ISoIP gateway through SmartWare.
CS interface configuration task list
Some parameters depend upon the interface type. If it is not specifically stated otherwise, the configuration
task is valid for all interfaces. Some parameters are generally set in other CS components than CS interfaces,
but can be overwritten in CS interfaces. This is not described in this chapter, but in chapter 20,
figuration" on page 235, and chapter 30,
interfaces you have to perform the configuration tasks listed below.
• Create and configure CS interfaces
• Configure call routing (see
• Configure digit collection (advanced) (see
• Configure direct call signaling on VoIP interfaces (see
• Specify the port address on VoIP interfaces (advanced) (see
• Bind PSTN interfaces to PSTN ports and create line hunt groups (see
Create and configure CS interfaces
To configure CS interfaces you have first to enter in the CS context mode. Once entered you can create and con-
figure your required interface by entering the CS interface configuration mode and specify the parameters. Each
interface has a name. The name can be any arbitrary string of not more than 25 characters. Use a name describing
the purpose of the interface as used in the examples or, for ease of identification, the interface type can be used as
part of the name. Already defined CS interfaces can be displayed or deleted as described in the table below.
Note
An interface is not defined and can not be displayed until a parameter in the
interface itself is set.
This procedure describes how to create and configure CS interfaces.
Mode: Configure
Step
1 node (cfg)#context cs
2 node (ctx-cs)[switch]#interface if-type if-name Enter the CS Interface Configuration Mode &
3 node (if-type)[ if-name ]#...
node (if-type)[ if-name ]#exit
4
5

CS interface configuration task list

"VoIP profile configuration"
page 298)
page
Command
on page 377. To create and configure CS
299)
page 300)
page 301)
page
Enter the CS Context Configuration Mode.
select the CS interface with type if-type and name
if-name for configuration.
Perform the configuration tasks to configure the
CS interface.
Go back to the CS Context Configuration Mode
Repeat steps 1 to 4 to create and configure your
CS interfaces
24 • CS interface configuration
"DHCP con-
303)
Purpose
297
