6 • System image handling
The available command set is shown in
Command
? Displays the main menu with available commands, domains and active sessions.
help Displays a list of the commands available in the current domain.
boot Restarts the system.
div d s The output of domain d is diverted to another session s, i.e. to Telnet interfaces.
sd d Switches to another domain. The available domains are displayed in the main
menu by entering ?. d = 0 invokes the Route Table Manager, d = 1 invokes the
Download Agent. d = 2 invokes the Diagnostics.
quit/quit s Terminates the current session/the session at Telnet interfaces.

Route Table Manager (RTM)

To access the Route Table Manager, type 'sd 0'.
66
table 6.
Table 6. Main Shell Command Set
Function
Figure 16. Main Shell
SmartWare Software Configuration Guide
Bootloader (for SmartNode 1000 and 2000 Series)
