18 • SNMP Configuration
Note The standard SNMP version 1 trap coldStart as listed below is not sup-
ported. After powering up a SmartNode 1000, 2000 or 4000 series device
sends a warmStart trap message if any trap target host is defined.

SNMP interface traps

The SmartNode emits Interface Traps ('linkUp', 'linkDown') when the status of logical or physical interfaces
change. Logical interfaces are interfaces defined in the IP context (IP interfaces) and interfaces defined in the
CS context (PSTN, ISoIP, and H323 interfaces). Physical interfaces are 'ports' in the SmartNode terminology
(Ethernet, ISDN, and Serial Ports).
The SmartNode assigns an index to each interface ('ifIndex') in order to identify the Interface Traps. These
assignments depend on the hardware and software configurations. The command 'show snmp-if-alias-map-
ping' displays the relations between the indexes and the interfaces. It also lists the status of the interfaces.
SN(cfg)#show snmp-if-alias-mapping
ifIndex :
---------------------------------------------------------------------
1 :
2 :
3 :
4 :
5 :
6 :
7 :
8 :
Interface names in capital letters denote physical interfaces and in small letters logical interfaces.
The SmartNode adds an entry to event log for each Interface Traps it sends:
SN(cfg)#show log
...
2002-09-06T14:54:35 : LOGINFO
2002-09-06T14:54:35 : LOGINFO
2002-09-06T14:54:35 : LOGINFO
2002-09-06T14:54:38 : LOGINFO
2002-09-06T14:54:38 : LOGINFO
2002-09-06T14:54:39 : LOGINFO
2002-09-06T14:54:39 : LOGINFO
2002-09-06T14:56:02 : LOGINFO
2002-09-10T14:21:20 : LOGINFO
...
222
Interface Name (Interface Type) Interface Status
h323_60
h323_30
isdn20
ETH00 (ethernet-csmacd)
ETH01 (ethernet-csmacd)
eth00
eth01
ISDN20
: Link up on interface h323_60.
: Link up on interface h323_30.
: Link up on interface isdn20.
: Link up on interface ETH00.
: Link up on interface ETH01.
: Link up on interface eth00.
: Link up on interface eth01.
: Link up on interface SLOT2:00 ISDN D
: Link down on interface SLOT2:00 ISDN
SmartWare Software Configuration Guide
(H323) up
(H323) up
(PSTN) up
up
up
(IP) up
(IP) up
(pstn) down

SNMP interface traps
