13 • Link scheduler configuration
Devoting the service policy profile to an interface
Any service policy profile needs to be bound to a certain IP interface to get activated. According the terminol-
ogy of SmartWare a service policy profile is used on a certain IP interface, as shown in
Therefore the use profile service-policy command allows attaching a certain service policy profile to an IP
interface that is defined within the IP context. The command offers an optional argument allowing to define
that the service policy profile is activated in receive or transmit direction.
Note
Be aware that service policy profiles can only be activated on the transmit
direction at the moment!
Providers may use input shaping to improve downlink voice jitter in the absence of voice support. The default
setting "no service-policy" sets the interface to FIFO queuing.
This procedure describes devoting a service policy profile to an IP interface that is defined within the IP con-
text
Mode: Interface
Step
node (if-ip)[ if-name ]#use profile service-
1
policy name {in | out}
Example: Devoting the service policy profile to an interface
156
Figure 38. Using a Service Policy Profile on an IP Interface
Command
SmartWare Software Configuration Guide
Purpose
Applies the service policy profile name to the
selected interface if-name . Depending on select-
ing the optional in or out argument the service
policy profile is active on the receive or transmit
direction. Be aware that service policy profiles
can only be activated on the transmit direction at
the moment.
Link scheduler configuration task list
figure 38.
