13 • Link scheduler configuration

Enable statistics gathering

Using the debug queue statistics commands enables statistic gathering of link scheduler operations.
The command has optional value, which defines the level of detail. The value is in the range from 1 to 6. In
table 12 below the values and their implications are compiled.
Note
The debug features offered by SmartWare require CPU resources of your
SmartNode. Therefore do not enable statistic gathering or other debug fea-
tures if it is not necessary. Disable any debug feature after use with the no
form of the command.
This procedure describes enabling the statistic gathering of link scheduler operations with a certain verbosity of
the command output.
Mode: Source
Step
1 node (src)[ name ]#debug queue statistics level Enables statistic gathering for the selected class
Example: Enable statistics gathering
The following example shows how to enable statistic gathering for the source class Web, which is defined in the
service policy profile Level_1. The level of verbosity for the command output is set to 6, which is very verbose.
SN>enable
SN#configure
SN(cfg)#profile service-policy Level_1
SN(pf-srvpl)[Level_1]#source class Web
SN(src)[Web]#debug queue statistics 6
158
Table 12. Values defining verbosity of command output
Optional Value Implication on Command Output
0 Statistic gathering is switched off
1 Display amount of packets transferred
2
3
4
5
6
Command
SmartWare Software Configuration Guide
Purpose
or policy name . The optional argument level ,
which is in the range from 1 to 6, defines the ver-
bosity of the command output.
