Delete An Image From The Flash Image Store; Redboot Configuration; Displaying Current Configuration - Patton electronics SmartNode Series Software Configuration Manual

B • Configuration mode overview

Delete an image from the Flash image store

Step 1 fis delete -n index
RedBoot Configuration
The following commands are used to manage the RedBoot configuration. The configuration is stored in persis-
tent memory and remains valid across system reboots.
Some of the options are changed by SmartWare to reflect the current SmartWare settings. In other words, it
will set the local IP address to the address actually configured in SmartWare.
Displaying current configuration
Step 1 fconfig -l
RedBoot> fconfig —l
Run script at boot
Boot script
.. fis load
.. go
Boot script timeout (1000ms resolution)
Use BOOTP for network configuration
Gateway IP address
Local IP address
Local IP address mask
Default server IP address
Force console for special debug messages
Network debug at boot time
436
Command
Command
SmartWare Software Configuration Guide
Purpose
Deletes an image from the Flash image store.
-n: Index of image to delete. If omitted the last
image is deleted. Otherwise the specified image
and all following images are deleted.
Purpose
Displays current configuration.
: true
:
: 5
: false
: 0.0.0.0
: 172.31.14.151
: 255.255.255.0
: 0.0.0.0
: false
: false
RedBoot Bootloader command set
