SmartWare Software Configuration Guide
Example: Called party number routing table
SN(cfg)#context cs
SN(ctx-cs)[switch]#called-party national 001 dest-interface USVoIP-A
SN(ctx-cs)[switch]#called-party national 001320 dest-interface USVoIP-B
SN(ctx-cs)[switch]#called-party national 0044 dest-interface EuroVoIP
SN(ctx-cs)[switch]#called-party national 0049 dest-interface EuroVoIP
SN(ctx-cs)[switch]#called-party national default dest-interface DefAcc

Create a calling party number routing table

The Calling Party Number (CnPN) table is used to route calls based on the CnPN in the call set-up message.
This number in general corresponds to the extension number of a PBX or MSN of an ISDN terminal. The
table can be used to route calls from extensions, which have particular call routing requirements (i.e. Terminals
which require non VoIP capable ISDN services). The Session Router looks for the longest match starting with
the last digit of the calling party number.
Note The calling party number is sometimes inserted or modified by a PBX.
This procedure describes how to create a CnPN routing table
Mode: Context CS
Step
1 node (ctx-cs)[ switch ]#calling-party tbl-name
key dest-interface if-name
or
node (ctx-cs)[ switch ]#calling-party tbl-name
key dest-table tbl-name
2
Example: Calling party number routing table
SN(ctx-cs)[switch]#calling-party exts 523 dest-interface breakout
SN(ctx-cs)[switch]#calling-party exts 525 dest-interface breakout
SN(ctx-cs)[switch]#calling-party exts 572 dest-interface DefAcc

Create a bearer capability routing table

The bearer capability table is used to route calls based on the bearer capability field in the ISDN setup message.
This can be used to differentiate between ISDN data services and ISDN speech connections.
Note
Terminals connected to analogue extensions (e.g. of a PBX) do not supply
bearer capability values in their call set-up. It is therefore up to the configura-
tion of the analogue port on the Terminal Adapter, NT or PBX to insert this
value. The configuration of this value is however often omitted or wrong.
Session router configuration task list
Command
25 • Session router configuration
Purpose
Create a CnPN routing table tbl-name with key key
for destination interface if-name or destination
table tbl-name by adding the first line.
Repeat step 1 to add lines for multiple table
entries.
317
