17 • Access control list configuration
Unbind an access control list profile from an interface.
SN(cfg)#context ip router
SN(cfg-ip)[router]#interface wan
SN(cfg-if)[wan]#no use profile acl in
Note
When unbinding an access control list profile the name argument is not
required, since only one incoming and outgoing access control list can be
active at the same time on a certain IP interface.
Display an access control list profile
The show profile acl command displays the indicated access control list profile. If no specific profile is selected
all installed access control list profiles are shown. If an access control list is linked to an IP interface the number
of matches for each rule is displayed. If the access control list profile is linked to more than one IP interface, it
will be shown for each interface.
This procedure describes how to display a certain access control list profile
Mode: Administrator execution or any other mode, except the operator execution mode
Step Command
1 node #show profile acl name
Example: Displaying an access control list entries
The following example shows how to display the access control list profile named WanRx.
SN#show profile acl WanRx
IP access-list WanRx. Linked to router/wan/in.
deny icmp any any msg echo
permit ip 62.1.2.3 0.0.255.255 host 193.14.2.11
permit ip 97.123.111.0 0.0.0.255 host 193.14.2.11
permit tcp any host 193.14.2.10 eq 80
permit udp host 62.1.2.3 host 193.14.2.11 range 1024 2048
deny ip any any
Debug an access control list profile
The debug acl command is used to debug the access control list profiles during system operation. Use the no
form of this command to disable any debug output.
This procedure describes how to debug the access control list profiles
Mode: Administrator execution or any other mode, except the operator execution
Step Command
1 node#debug acl
This procedure describes how to activate the debug level of an access control list profiles for a specific interface.
204
Displays the access control list profile name
Enables access control list debug monitor
SmartWare Software Configuration Guide
Purpose
Purpose
Access Control List configuration task list
