25 • Session router configuration
Mode: Context CS
Step
1 node (ctx-cs)[ switch ]#date tbl-name key
dest-interface if-name
or
node (ctx-cs)[switch]#date tbl-name key
dest-table tbl-name
2
Example: Date routing table
SN(ctx-cs)[switch]#date holiday2001 2001/01/01 dest-table leastCost
SN(ctx-cs)[switch]#date holiday2001 2001/01/02 dest-table leastCost
SN(ctx-cs)[switch]#date holiday2001 2001/05/01 dest-table leastCost
SN(ctx-cs)[switch]#date holiday2001 2001/12/24-2002/01/02 dest-table leastCost
SN(ctx-cs)[switch]#date holiday2001 default dest-interface VoIPCarrierA

Create a presentation indicator routing table

The presentation indicator defines whether the calling party number may be presented at the called party.
Routing decision may be base on this information.
Procedure: To create a presentation indicator routing table
Mode: Context CS
Step
node (ctx-cs)[ switch ]#presentation-indi-
1
cator tbl-name { allowed | restricted |
interworking | default } dest-interface
if-name
or
node (ctx-cs)[ switch ]# presentation-
indicator tbl-name { allowed | restricted
| interworking | default } dest-table
tbl-name
2
Example: Presentation Indicator Routing Table
Reject calls that do not allow to present the calling party number:
SN(ctx-cs)[switch]#presentation-indicator allowed dest-interface myTerminal
320
Command
Command
SmartWare Software Configuration Guide
Purpose
Create a time routing table by adding the first line.
Repeat step 1 to add lines for multiple table
entries.
Purpose
Create a presentation indicator routing
table by adding the first line.
Repeat step 1 to add lines for multiple
table entries.
Session router configuration task list
