29 • Gateway configuration
Mode: Gateway H.323
Step
1 node (gw-h323)[h323]#gatekeeper-
discovery auto [ gkid ]
or
node (gw-h323)[h323]#gatekeeper-
discovery manual ip-address ip-port
[gkid]
node (gw-h323)[h323]#alias h323-id
2
name
or
node (gw-h323)[h323]#alias e164
number
3
4 node (gw-h323)[h323]#supported-prefix
prefix
5
node (gw-h323)[h323]#ras
6
Example: Configuring registration authentication service
The following example shows how to configure the registration authentication service for a SmartNode in an
H.323 network.
SN>enable
SN#configure
SN(cfg) #gateway h323 h323
SN(gw-h323)[h323]#gatekeeper-discovery auto
SN(gw-h323)[h323]#alias h323-id Berne1
SN(gw-h323)[h323]#alias e164 007
SN(gw-h323)[h323]#alias e164 *5
SN(gw-h323)[h323]#alias e164 19421
SN(gw-h323)[h323]#1supported-prefix 03198525
SN(gw-h323)[h323]#ras

H.323 registration authentication service gatekeeper registration type

H.323 gatekeepers usually allow configuring the registration type (terminal or gateway) of the registrant (regis-
tration authentication service). For administrative purposes it may be desirable to change the registration type
on the gatekeeper. The gateway however needs to register with the same registration type; registration type mis-
match may result in registration failure.
This procedure describes how to configure the registration type of the registration with the gatekeeper
366
Command
SmartWare Software Configuration Guide
Purpose
Specify that the gatekeeper discovery has to be
done automatically
or
Specify the gatekeeper for the SmartNode explic-
itly.
Sets the identifier(s) for registration on the gate-
keeper with a string
or
with a phone number
Repeat step 2 to add more that one alias to the
configuration.
Registers a prefix with the gatekeeper. The gate-
keeper will route a calls with called party numbers
starting with this prefix to this SmartNode
Repeat step 4 to add more that one prefix to the
configuration.
Enable the registration authentication service proto-
col for gatekeeper registration and client resolution
Gateway configuration task list
