chain A linked set of lines or walls. When drawing walls or lines in a building model, you can simplify the
process by drawing a chain. You can also select a chain of lines or walls to manipulate them simultaneously.
clean To resolve joins between 2 or more host elements that share a common face, such as walls and floors.
When a view shows a coarse level of detail, Revit Architecture removes visible lines between the elements.
When a view shows a fine level of detail, Revit Architecture shows precisely how the layers of compound
walls or other structures join together. The cleaned join applies only to the current view.
See Wall Joins on page 651 and Joining Geometry on page 406.
Before joining the roof and the soffit
After joining the roof and the soffit
clip plane A vertical or horizontal plane that defines a boundary for a view. You can use top, bottom, left,
and right clip planes to define a view. In elevation and section views, you can also use a far clip plane to
define the depth of the view.
