Programming Guide | VLT® HVAC Drive FC 102
All parameters can be changed in the Main Menu. However, depending on the choice of configuration (parameter 1-00 Configuration
Mode), some parameters can be hidden. For example, open loop hides all the PID parameters, and other enabled options make more
parameter groups visible.

Parameter Selection

5.1.14
In the main menu mode, the parameters are divided into groups. Select a parameter group with the navigation keys.
After selecting a parameter group, select a parameter with the navigation keys.
The middle section on the display shows the parameter number and name, and the selected parameter value.
740RPM 10.64A
Basic Settings
0 -01 Language
[0] English
Figure 17: Parameter Selection

Changing Data

5.1.15
The procedure for changing data in the quick menu mode and the main menu mode is the same. Press [OK] to change the selected
parameter.
The procedure for changing data depends on whether the selected parameter represents a numeric data value or a text value.

Changing a Text Value

5.1.16
If the selected parameter is a text value, change the text value with the [▲] [▼] keys.
Place the cursor on the value to save and press [OK].
740RPM 10.64 A
Basic Settings
0 -01 Language
[0] English
Figure 18: Changing a Text Value

Changing a Data Value

5.1.17
If the selected parameter shows a numeric data value, change the selected data value with the [◄] [►] and the [▲] [▼] navigation keys.
Press the [◄] [►] keys to move the cursor horizontally.
© 2024.10
1 [1]
0-0*
1 [1]
0-0 *
How to Program
AU430028034214en-001901 / 130R0310 | 43
