Programming Guide | VLT® HVAC Drive FC 102
1-05 Local Mode Configuration
Default value: [0] Open loop
Setup: All setups
Data type: Uint8
Select which application configuration mode (parameter 1-00 Configuration Mode), that is application control principle, to use when a
local (LCP) reference is active. A local reference can be active only when parameter 3-13 Reference Site is set to [0] Linked to Hand/Auto
or [2] Local. By default the local reference is active in hand-on mode only.
Option Name
[0]* Open loop
[2] As mode par. 1-00
1-06 Clockwise Direction
Default value: [0] Normal
Setup:
All setups
Data type: Uint8
This parameter cannot be adjusted while the motor is running.
This parameter defines the term clockwise corresponding to the LCP direction arrow. Used for easy change of direction of shaft rotation
without swapping motor wires.
Option Name
[0]* Normal
[1] Inverse
[2] Inverse all

Motor Selection

6.3.2

Active Parameters, Induction and PM Non-salient Motors

6.3.2.1
This parameter group cannot be adjusted while the motor is running.
© 2024.10
Parameter type:
Conversion index:
Change during operation:
Description
Parameter type:
Conversion index:
Change during operation:
NOTICE
Description
The motor shaft turns in clockwise direction when the drive is
connected U⇨U, V⇨V, and W⇨W to the motor.
The motor shaft turns in counterclockwise direction when the
drive is connected U⇨U, V⇨V, and W⇨W to the motor.
Inverts motor direction, feedback direction, and angle offset on
PM motor.
NOTICE
Parameter Descriptions
Option
–
True
Option
–
False
AU430028034214en-001901 / 130R0310 | 83
