Programming Guide | VLT® HVAC Drive FC 102
Table 84: Description of Extended Status Word
Bit Hex
12 00001000
13 00002000
14 00004000
15 00008000
16 00010000
17 00020000
18 00040000
19 00080000
20 00100000
21 00200000
22 00400000
724 | © 2024.10
(continued)
Dec Ext. status word
Parameter 16-94
Ext. Status Word
4096 Braking max.
BrakePower >
parameter 2-12
Brake Power Limit
[kW]
8192 Braking
16384 Out of speed range
32768 OVC active
65536 AC brake
131072 Password timelock
number of allowed
password trials ex-
ceeded - timelock
active
262144 Password protec-
tion
0-61 =
ALL_NO_ACCESS
OR
BUS_NO_ACCESS
OR
BUS_READONLY
524288 Reference high
reference
>parameter 4-55
Warning Reference
High
1048576 Reference low
Reference <
parameter 4-54
Warning Reference
Low
2097152 Local reference
Reference site = RE-
MOTE -> auto on
pressed & active
4194304 Protection mode
Troubleshooting
Ext. status word 2 Ext. status word 3
Parameter 16-95 Parameter 16-99
Ext. Status Word 2 Ext. Status Word 3
Standby –
Freeze output re- –
quest
Freeze output –
Jog request –
Jog –
Start request –
Start –
Start applied –
Start delay –
Sleep –
Sleep boost –
