Programming Guide | VLT® HVAC Drive FC 102
Set the DC brake cut-in speed for activation of the DC brake current set in parameter 2-01 DC Brake Current, upon a stop command.
2-04 DC Brake Cut In Speed [Hz]
Default value: Size
Setup: All setups
Data type: Uint16
Parameter 2-04 DC Brake Cut In Speed [Hz] is not effective when parameter 1-10 Motor Construction = [1] PM, nonsalient SPM.
Set the DC brake cut-in speed for activation of the DC brake current set in parameter 2-01 DC Brake Current, upon a stop command.
2-06 Parking Current
Default value: 50%
Setup: All setups
Data type:
Uint16
Set current as percentage of rated motor current, parameter 1-24 Motor Current. Is used when enabled in parameter 1-70 Start Mode.
2-07 Parking Time
Default value: 3 s
Setup:
All setups
Data type: Uint16
Set the duration of the parking current set in parameter 2-06 Parking Current, once activated.

2-1* Brake Energy Funct.

6.4.2
Parameter group for selecting dynamic brake parameters. Only valid for drives with brake chopper.
2-10 Brake Function
Default value: –
Setup:
All setups
Data type: Uint8
© 2024.10
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
Range, 0 - 0 Hz
-1
True
Range, 0 - 1000%
0
True
Range, 0.1 - 60 s
-1
True
Option
–
True
AU430028034214en-001901 / 130R0310 | 119
