Programming Guide | VLT® HVAC Drive FC 102
The damping gain stabilizes the PM machine to run smoothly and with stability. The value of damping gain controls the dynamic
performance of the PM machine. High damping gain gives high dynamic performance and low damping gain gives low dynamic
performance. The dynamic performance is related to the machine data and load type. If the damping gain is too high or low, the control
becomes unstable.
1-15 Low Speed Filter Time Const.
Default value: Size related
Setup:
All setups
Data type: Uint16
The time constant is used below 10% rated speed. Obtain quick control through a short dampening time constant. However, if this value
is too short, the control becomes unstable.
1-16 High Speed Filter Time Const.
Default value:
Size related
Setup: All setups
Data type:
Uint16
The time constant is used above 10% rated speed. Obtain quick control through a short dampening time constant. However, if this value
is too short, the control becomes unstable.
1-17 Voltage Filter Time Const.
Default value:
Size related
Setup: All setups
Data type: Uint16
Reduces the influence of high frequency ripple and system resonance in the calculation of supply voltage. Without this filter, the ripples
in the currents can distort the calculated voltage and affect the stability of the system.

1-2* Motor Data

6.3.5
This parameter group contains input data from the nameplate on the connected motor.
Changing the value of these parameters affects the setting of other parameters.
The following parameters have no effect when parameter 1-10 Motor Construction is set to [1] PM, non-salient SPM, [2] PM,
salient IPM, [5] Sync. reluctance.
Parameter 1-20 Motor Power [kW]
l
Parameter 1-21 Motor Power [HP]
l
Parameter 1-22 Motor Voltage
l
Parameter 1-23 Motor Frequency
l
88 | © 2024.10
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
NOTICE
NOTICE
Parameter Descriptions
Range, 0.01 - 20 s
-2
True
Range, 0.01 - 20 s
-2
True
Range, 0.001 - 2 s
-3
True
AU430028034214en-001901 / 130R0310
