Programming Guide | VLT® HVAC Drive FC 102
Table 30: Digital Outputs, Function Descriptions
Option
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[76] Logic rule 6
[77] Logic rule 7
[78] Logic rule 8
[79] Logic rule 9
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
168 | © 2024.10
(continued)
Function
See parameter group 13-4* Logic Rules. If logic rule 2 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 3 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 4 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 5 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 6 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 7 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 8 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 9 is evaluated
as true, the output goes high. Otherwise, it is low.
See parameter 13-52 SL Controller Action. The output goes high
whenever the smart logic action [38] Set dig. out. A high is exe-
cuted. The output goes low whenever the smart logic action [32]
Set dig. out. A low is executed.
See parameter 13-52 SL Controller Action. The output goes high
whenever the smart logic action [39] Set dig. out. B high is exe-
cuted. The output goes low whenever the smart logic action [33]
Set dig. out. B low is executed.
See parameter 13-52 SL Controller Action. The output goes high
whenever the smart logic action [40] Set dig. out. C high is exe-
cuted. The output goes low whenever the smart logic action [34]
Set dig. out. C low is executed.
See parameter 13-52 SL Controller Action. The output goes high
whenever the smart logic action [41] Set dig. out. D high is exe-
cuted. The output goes low whenever the smart logic action [35]
Set dig. out. D low is executed.
See parameter 13-52 SL Controller Action. The output goes high
whenever the smart logic action [42] Set dig. out. E high is exe-
cuted. The output goes low whenever the smart logic action [36]
Set dig. out. E low is executed.
See parameter 13-52 SL Controller Action. The output goes high
whenever the smart logic action [43] Set dig. out. F high is exe-
cuted. The output goes low whenever the smart logic action [37]
Set dig. out. F low is executed.
Parameter Descriptions
