Programming Guide | VLT® HVAC Drive FC 102
Setup: 1 setup
Data type: Uint16
Holds the preset level of terminal X42/7. If a fieldbus and a timeout function are selected in parameter 26-50 Terminal X42/9 Output, the
output presets to this level.
6.26.7 26-5* Analog Out X42/9
This parameter group contains parameters for configuring the scaling and output function for analog output terminal X42/9.
26-50 Terminal X42/9 Output
Default value:
[0] No operation
Setup: All setups
Data type: Uint8
Set the function of terminal X42/9 as an analog current output.
Option Name
[0]* No operation
[52] MCO
[86] Pressure sensor 1
[88] Pressure sensor 2
[93] Pressure sensor 3
[100] Output freq. 0–100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0–Imax
[104] Torque 0–Tlim
[105] Torque 0–Tnom
[106] Power 0–Pnom
[107] Speed 0–HighLim
[113] Ext. closed loop 1
[114] Ext. closed loop 2
[115] Ext. closed loop 3
[117] Shaft power
[121] Air pres. to flow
[139] Bus ctrl
© 2024.10
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
0–100 Hz, (0–10 V)
Minimum reference–maximum reference, (0–10 V).
-200%...+200% of parameter 3-03 Maximum Reference (0–10 V)
0–inverter maximum current (parameter 16-37 Inv. Max.
Current), (0–10 V).
0–torque limit (parameter 4-16 Torque Limit Motor Mode ), (0–10
V).
0–motor rated torque, (0–10 V).
0–motor rated power, (0–10 V).
0–speed high limit (parameter 4-13 Motor Speed High Limit
[RPM] and parameter 4-14 Motor Speed High Limit [Hz]), (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
-2
True
Option
–
True
