Programming Guide | VLT® HVAC Drive FC 102
Table 30: Digital Outputs, Function Descriptions
Option
[181] Prev. maintenance
[188] AHF capacitor connect
[189] External fan control
[190] No-flow
[191] Dry pump
[192] End of curve
[193] Sleep mode
[194] Broken belt
[195] Bypass valve control
[196] Fire mode
[197] Fire mode was act.
[198] Drive bypass
[200] Full capacity
[201] Pump 1 running
170 | © 2024.10
(continued)
Function
One or more of the preventive maintenance events programmed
in 23-10 Maintenance Item has passed the time for the specified
action is parameter 23-11 Maintenance Action.
The capacitors are turned on at 20% (hysteresis of 50% gives
an interval of 10–30%). The capacitors are disconnected below
10%. The off delay is 10 s and restarts if the nominal power goes
above 10% during the delay. Parameter 5-80 AHF Cap Reconnect
Delayis used to guarantee a minimum off time for the capacitors.
The internal logics for the internal fan control is transferred to
this output to make it possible to control an external fan (rele-
vant for hp duct cooling).
The drive/system entered sleep mode. See parameter 22-4* Sleep
Mode.
A broken-belt condition has been detected. This function must
be enabled in parameter 22-60 Broken Belt Function.
The drive operates in fire mode. See parameter group 24-0* Fire
Mode.
The drive has been operating in fire mode. In software ver-
sion 7.3x, this output is only active 1 minute after fire mode is
stopped. See parameter group 24-0* Fire Mode.
To be used as signal for activating an external electromechanical
bypass, switching the motor direct on line. See parameter group
24-1* Drive Bypass.
All pumps running at full speed.
One or more pumps controlled by the cascade controlled are
running. The function also depends on parameter 25-06 Number
of Pumps. If set to [0] No, pump 1 refers to the pump controlled
by relay 1, and so on. If set to [1] Yes, pump 1 refers to the pump
controlled by the drive only (without any of the built-in relays in-
volved), and pump 2 refers to the controlled by relay 1.
NOTICE
If enabling the drive bypass function, the drive is no
longer certified for using the Safe Torque Off in versions
where included.
AU430028034214en-001901 / 130R0310
Parameter Descriptions
