Programming Guide | VLT® HVAC Drive FC 102
Setup: All setups
Data type: Uint8
This parameter makes it possible to enable the live zero monitoring, for example, where the analog input is the drive control, rather than
being used as a decentral I/O system, such as a building management system. If set for temperature and used as feedback, set the unit
for either Celsius or Fahrenheit.
Option Name
[0] Disabled
[1]* Enabled
26-4* Analog Out X42/7
6.26.6
This parameter group contains parameters for configuring the scaling and output function for analog output terminal X42/7.
26-40 Terminal X42/7 Output
Default value: [0] No operation
Setup: All setups
Data type: Uint8
Set the function of terminal X42/7 as an analog current output.
Option Name
[0]* No operation
[52] MCO
[86] Pressure sensor 1
[88] Pressure sensor 2
[93] Pressure sensor 3
[100] Output freq. 0–100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0–Imax
[104] Torque 0–Tlim
[105] Torque 0–Tnom
[106] Power 0–Pnom
[107] Speed 0–HighLim
© 2024.10
Conversion index:
Change during operation:
Description
Parameter type:
Conversion index:
Change during operation:
Description
0–100 Hz, (0–10 V)
Minimum reference–maximum reference, (0–10 V).
-200%...+200% of parameter 3-03 Maximum Reference (0–10 V)
0–inverter maximum current ( parameter 16-37 Inv. Max.
Current), (0–10 V).
0–torque limit (parameter 4-16 Torque Limit Motor Mode ), (0–10
V).
0–motor rated torque, (0–10 V).
0–motor rated power, (0–10 V).
0–speed high limit ( parameter 4-13 Motor Speed High Limit
[RPM] and parameter 4-14 Motor Speed High Limit [Hz] ), (0–10
V).
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
–
True
Option
–
True
