Enter the I value. When the motor current exceeds this limit, the display reads Current High. The signal outputs can be programmed to
HIGH
produce a status signal on terminal 27 or 29.
4-52 Warning Speed Low
Default value: 0 RPM
Setup:
All setups
Data type: Uint16
Enter the n value. When the motor speed exceeds this limit, the display reads Speed low. The signal outputs can be programmed to
LOW
produce a status signal on terminal 27 or 29 and on relay output 01 or 02.
4-53 Warning Speed High
Default value: Size related
Setup:
All setups
Data type: Uint16
Enter the n value. When the motor speed exceeds this value, the display reads Speed high. The signal outputs can be programmed to
HIGH
produce a status signal on terminals 27 or 29 and on relay outputs 01 or 02.
4-54 Warning Reference Low
Default value: -999999.999
Setup:
All setups
Data type: Int32
Enter the lower reference limit. When the actual reference drops below this limit, the display indicates Ref
programmed to produce a status signal on terminal 27 or 29 and on relay output 01 or 02.
4-55 Warning Reference High
Default value: 999999.999
Setup:
All setups
Data type: Int32
Enter the upper reference limit. When the actual reference exceeds this limit, the display reads Ref
programmed to produce a status signal on terminal 27 or 29 and on relay output 01 or 02.
4-56 Warning Feedback Low
Default value: -999999.99ProcessCtrlUnit
Setup: All setups
