Danfoss VLT FC 102 Programming Manual page 133

Programming Guide | VLT® HVAC Drive FC 102
3-41 Ramp 1 Ramp Up Time
Default value: Size related
Setup: All setups
Data type: Uint32
Enter the ramp-up time, that is the acceleration time from 0 RPM to the synchronous motor speed n
prevents the output current from exceeding the current limit in parameter 4-18 Current Limit during ramping. The value 0.00
corresponds to 0.01 s in speed mode. See ramp-down time in parameter 3-42 Ramp 1 Ramp Down Time.
3-42 Ramp 1 Ramp Down Time
Default value:
Size related
Setup: All setups
Data type:
Uint32
Enter the ramp-down time, that is the deceleration time from the synchronous motor speed n
that no overvoltage occurs in the inverter due to regenerative operation of the motor, and such that the generated current does not
exceed the current limit set in parameter 4-18 Current Limit. The value 0.00 corresponds to 0.01 s in speed mode. See ramp-up time in
parameter 3-41 Ramp 1 Ramp Up Time.
3-5* Ramp 2
6.5.4
3-51 Ramp 2 Ramp Up Time
Default value:
Size related
Setup: All setups
Data type:
Uint32
Enter the ramp-up time, that is the acceleration time from 0 RPM to the nominal motor speed ns. Select a ramp-up time such that the
output current does not exceed the current limit in parameter 4-18 Current Limit during ramping. The value 0.00 corresponds to 0.01 s in
speed mode. See ramp-down time in parameter 3-52 Ramp 2 Ramp Down Time.
3-52 Ramp 2 Ramp Down Time
Default value:
Size related
Setup: All setups
Data type:
Uint32
Enter the ramp-down time, that is the deceleration time from the nominal motor speed n
no overvoltage occurs in the drive due to regenerative operation of the motor, and such that the generated current does not exceed the
current limit set in parameter 4-18 Current Limit. The value 0.00 corresponds to 0.01 s in speed mode. See ramp-up time in parameter
3-51 Ramp 2 Ramp Up Time.
© 2024.10
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
to 0 RPM. Select a ramp-down time such
s
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
to 0 RPM. Select a ramp-down time such that
s
AU430028034214en-00
Parameter Descriptions
Range, 1.00 - 3600 s
-2
True
. Select a ramp-up time which
S
Range, 1.00 - 3600 s
-2
True
Range, 1.00 - 3600 s
-2
True
Range, 1.00 - 3600 s
-2
True
19 01 / 130R0310 | 133
