Table 21: Digital Input Functions and Terminals
Digital input function
Run permissive
Hand start
Auto start
DigiPot increase
DigiPot decrease
DigiPot clear
Counter A (up)
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset Counter B
Sleep mode
Timed actions disabled
Constant OFF actions
Constant ON actions
MCO specific
Reset maint. word
PTC card 1
Mains loss
Mains loss inverse
Lead pump start
Lead pump alternation
Pump 1 interlock
Pump 2 interlock
Pump 3 interlock
Pump 1 inverse interlock
Pump 2 inverse interlock
Pump 3 inverse interlock
Fire mode ref bit 0
Fire mode ref bit 1
Fire mode ref bit 2
148 | © 2024.10
(continued)
Select
[52]
[53]
[54]
[55]
[56]
[57]
[60]
[61]
[62]
[63]
[64]
[65]
[66]
[68]
[69]
[70]
[75]
[78]
[80]
[96]
[97]
[120]
[121]
[130]
[131]
[132]
[139]
[140]
[141]
[190]
[191]
[192]
