Programming Guide | VLT® HVAC Drive FC 102
Option Name
[189] External fan control
[190] No-flow
[191] Dry pump
[192] End of curve
[193] Sleep mode
[194] Broken belt
[195] Bypass valve control
[196] Fire mode
[197] Fire mode was act.
[198] Drive bypass
[211] Cascade pump 1
[212] Cascade pump 2
[213] Cascade pump 3
[234] PE power off
[236] Ext. CL 1 on ref
[237] Ext. CL 2 on ref
[238] Ext. CL 3 on ref
[240] RS flipflop 0
[241] RS flipflop 1
[242] RS flipflop 2
[243] RS flipflop 3
[244] RS flipflop 4
© 2024.10
Description
The internal logics for internal fan control is transferred to this
output to make it possible to control an external fan (relevant for
hp duct cooling).
The drive/system has entered sleep mode. See parameter group
22-4* Sleep Mode.
A broken-belt condition has been detected. Enable this function
in parameter 22-60 Broken Belt Function.
The drive operates in fire mode. See parameter group 24-0* Fire
Mode.
The drive has been operating in fire mode. In software version
7.2X, this output is only active 1 min after fire mode is stopped.
See parameter 24-0* Fire Mode.
To be used as signal for activating an external electromechanical
bypass, switching the motor direct on line. See parameter group
24-1* Drive Bypass.
LOSS OF CERTIFICATION
If enabling the drive bypass function, the drive is no
longer certified for using the Safe Torque Off in versions
where included.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
NOTICE
181
