Programming Guide | VLT® HVAC Drive FC 102
Option Name
[170] psi
[171]
lb/in
[172] in WG
[173] ft WG
[174] in HG
[180] hp
21-11 Ext. 1 Minimum Reference
Default value: 0 ExtPID1Unit
Setup: All setups
Data type: Int32
Select the minimum reference for the closed-loop 1 controller.
21-12 Ext. Maximum Reference
Default value:
100 ExtPID1Unit
Setup: All setups
Data type:
Int32
Set the value for parameter 21-12 Ext. 1 Maximum Reference before setting the values for the PID controller in parameter group
20-9* PID Controller.
Select the maximum reference for the closed-loop 1 controller. The dynamics of the PID controller depend on the value set in this
parameter. See also parameter 21-21 Ext. 1 Proportional Gain.
21-13 Ext. 1 Reference Source
Default value: [0] No function
Setup:
All setups
Data type: Uint8
If feedback is not used, set its source to [0] No function. Parameter 20-20 Feedback Functiondetermines how the PID controller
uses the 3 possible feedbacks.
This parameter defines which input on the drive should be treated as the source of the reference signal for the closed-loop 1 controller.
Analog input X30/11 and analog input X30/12 refer to inputs on the VLT® General Purpose I/O Card MCB 101.
472 | © 2024.10
2
Description
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter Descriptions
Range, -999999.999 - par.
21-12 Ext.PID1Unit
-3
True
Range, par. 21-11 - 999999.999
Ext.PID1Unit
-3
True
Option
–
True
AU430028034214en-001901 / 130R0310
