Programming Guide | VLT® HVAC Drive FC 102
Option Name
[0] ISO 8859-1
[1] ANSI X3.4
[2] UTF-8

8-1* Ctrl. Word Settings

6.10.2
8-10 Control Word Profile
Default value: [0] FC profile
Setup: All setups
Data type: Uint8
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the selections valid for the fieldbus
installed in slot A are visible in the LCP display. For guidelines in selection of [0] FC profile and [1] PROFIdrive profile, refer to the product-
specific design guide. For more guidelines in the selection of [1] PROFIdrive profile, refer to the Installation Guide for the installed
fieldbus.
Option Name
[0]* FC profile
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
[22] PROFIdrive v4_2 profile
8–13 Configurable Status Word STW
Default value: [1] Profile default
Setup: All setups
Data type: Uint8
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the selections valid for the fieldbus
installed in slot A are visible in the LCP display. For more guidelines in the selection of [1] PROFIdrive profile, refer to the Installation
Guide for the installed fieldbus.
Option Name
[0] No function
[1]* Profile default
[2] Alarm 68 Only
© 2024.10
Description
Parameter type:
Conversion index:
Change during operation:
Description
Available only with VLT® DeviceNet MCA 104 and VLT® EtherNet/
IP MCA 121.
Parameter type:
Conversion index:
Change during operation:
Description
The input is always low.
Dependent on the profile set in parameter 8–10 Control Profile.
The input goes high whenever Alarm 68, Safe Stop Activated is
active and goes low whenever Alarm 68, Safe Stop Activated is
not active.
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
Option
–
True
Option, Array [16]
–
True
225
